Technical data
Ratio
1:4
Work capacity:max. diameter
36 mm
Max. module
1.00
Workpiece length max.
80 mm
Pitch min.
6
max.
200
Axes distance between work-
piece and tool:
max
30 mm
Gear hob:
max. diameter
36 mm
Max. milling cutter displac.
50 mm
Milling cutter speeds:
number (steps)
8
from
660 rpm
up to
5300 rpm
Voltage 50 Hz 3x
380 Volt
Power
0.60 HP
Total power required
1.5 HP
Machine's weight about
450 kg
Overall dimensions machine:
Length
780 mm
Width
730 mm
Height
1380 mm
Various accessories:
Lamp
Coolant system
Technical specifications and pictures without guarantee.
