Technical data
Grinding wheels:
Diameter
175 mm
Width
20 mm
Bore
20 mm
Spindle speeds:
up to
2800 rpm
Tool orthogonal clearance
max.
26 °
Clamping range of the tools:
Width
32 mm
Height
32 mm
Voltage 50 Hz 3x
380 Volt
Power
1.0 HP
Machine's weight about
300 kg
Overall dimensions machine:
Length
820 mm
Width
564 mm
Height
1215 mm
Various accessories:
Inclinable tool holder
Steady for Tollholders
Technical specifications and pictures without guarantee.
