Technical data
Table length
1200 mm
Table width
270 mm
Number of T-channels
3
T-channel width
16 mm
Distance of the T-slots
65 mm
Longitudinal travel (X-axis)
760 mm
Transversal travel (y axis)
340 mm
Vertical travel (z axis)
410 mm
Spindle speeds:
number (steps)
12
from
35 rpm
up to
1600 rpm
Taper in spindle
40 ISO
Voltage 50 Hz 3x
380 Volt
Spindle motor
2.2 kW
Machine's weight about
2000 kg
Overall dimensions machine:
Length
2000 mm
Width
1800 mm
Height
1800 mm
Technical specifications and pictures without guarantee.
