Technical data
Centre height
115 mm
Distance between centres
500 mm
Max. grinding length
320 mm
Max. grinding diameter
260 mm
Axial motion:
Longitudinal
340 mm
Vertical
270 mm
B axis (grinding head rotation)
360 °
Grinding spindle speeds:
from
3650 rpm
up to
6100 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
0.75 kW
Machine's weight about
700 kg
Overall dimensions machine:
Length
1375 mm
Width
1325 mm
Height
1500 mm
Technical specifications and pictures without guarantee.
