Technical data
Number of axis simultaneous
5
Centre height
210 mm
Grinding-wheel diameter
200 mm
Taper in spindle
40 ISO
Axial motion:
Crosswise
400 mm
Longitudinal
200 mm
Vertical
310 mm
A axis (grinding head rotaion)
+/- 120 °
Resolution
0.001 °
A axis
360 °
Grinding spindle speeds:
number (steps)
2
from
2740 rpm
up to
5480 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
2.4 / 3 kW
Machine's weight about
3300 kg
Overall dimensions machine:
Length
1750 mm
Width
1600 mm
Height
2100 mm
Technical specifications and pictures without guarantee.
